1.2M C Glass fiber reinforced unsaturated polyester sheet molding compound SMC
收藏
商品说明
Satellite antenna features and parameters： Main tech parameters： Frequency range：10.75-12.95GHZ 13.75-14.5GHz Gain：41.7dB 3dB ：1.4° First Sidelobe：-23dB Polarization isolation：>30dB VSWR：<1.2:1 Noise temperature (at 30 º elevation)：43 ºK Tilt / azimuth: manual adjustment：0°—360° Elevation adjustment range：10°—70° Feed interface：WR75 Wind loading rating：operation under 10,normal under 12 wind Temperature：-45℃ - 120℃ Humidity：5% -95% Atmospheric Conditions : Salt ,Pollutants and Contaminants as encountered in coastal and industrial areas . Reflector material：
