Norsat OMT TRANSMIT Ku馈源

Transmitter port frequency range

Transmitter port VSWR maximum

LNB port frequency range

LNB port VSWR maximum

Transmitter/LNB cross   polarization minimum

Transmitter port to LNB   port isolation at Tx frequency minimum

Transmitter port to feed   port insertion loss maximum

Feed port to LNB port insertion

loss maximum

13.75 to   14.50 GHz

1.25 : 1

10.70 to   12.75 GHz

1.25 : 1

40 dB   85 dB

0.2 dB

0.4 dB

Feedhorn port waveguide

Transmitter port waveguide

LNB port waveguide

Dimensions

Weight

WC75 with   threaded holes

WR75 with   through holes

WR75 with   through holes

108 (L) x   149 (W) x 117 (H) mm (4.25 x 1.93 x 4.59 in)

390 g / 13.8 oz max
