Norsat 3420N PLL LNB 诺赛特锁相环高频头 降频器

Norsat 3420N PLL  LNB 诺赛特锁相环高频头 降频器 优质频稳定度

Frequency Band (GHz) 3.40 to 4.20

L.O. Frequency (GHz) 5.15

IF Frequency (MHz) 950 to 1750

Noise Temperature 37K typ., 60K max. at room temp. @ CF

Phase Noise (SSB) max. -80 dBc/Hz at 1kHz

-85 dBc/Hz at 10kHz

-95 dBc/Hz at 100kHz

Input VSWR 2.2 : 1 max.

Output VSWR 2.5 : 1 max.

Gain 60 dB typ., 55 dB min., 70 dB max.

Gain Flatness ≤ 6 dB p-p

(over full band)

Output P1dB + 9 dBm min.

Interference Rejection Signal -25 dBm max. with no degradation

DC Power + 12V to + 24 V DC

Current 250 mA max.

Input (waterproof) CPR229G waveguide grooved

Output (waterproof) F-Connector (75 Ohm)

N-Connector (50 Ohm)

Dimensions (L x W x H) 145 mm x 70 mm x 99 mm

(5.7 in x 2.8 in x 3.9 in)

Weight 500 g (17.64 oz)

Operating Temperature - 40 to + 60°C

Storage Temperature - 40 to + 80˚C
